M5Stack M5StickC Plus - ESP32 Development Board (2025)

Je moet inloggen of registreren om een beoordeling te plaatsen.

Beoordelingen over M5Stack M5StickC Plus - ESP32 Development Board

Dit product heeft in totaal 1 beoordeling(en).

\r\n\r\n

    \r\n\t
  • Voedingspanning: 3.3V (via 3V3 pin) of 5V DC (via USB-C poort of 5V pin)
  • \r\n\t
  • GPIO voltage: 3.3V
  • \r\n\t
  • Ingangsstroom: max 500mA
  • \r\n\t
  • Chipset: ESP32 PICO D4 (240MHz dual core processor)\r\n\t
      \r\n\t\t
    • Flashgeheugen: 4MB
    • \r\n\t\t
    • SRAM: 520KB
    • \r\n\t\t
    • PSRAM: 4MB
    • \r\n\t\t
    • Ingebouwde Wi-Fi
    • \r\n\t\t
    • Ingebouwde Bluetooth(BLE 4.2)
    • \r\n\t
    \r\n\t
  • \r\n\t
  • Programmeertalen: UIFlow, MicroPython, Arduino
  • \r\n\t
  • Input interface: USB-C, GROVE (I2C+I/0+UART)
  • \r\n\t
  • Knoppen: A (onder scherm), B (rechterzijde), aan/uit knop (linkerzijde).
  • \r\n\t
  • Scherm: 1.14 inch, 135x240 TFT LCD
  • \r\n\t
  • Batterij*: 120mAh
  • \r\n\t
  • Ingebouwde buzzer
  • \r\n\t
  • Ingebouwde microfoon: SPM1423
  • \r\n\t
  • Ingebouwde IR transmitter
  • \r\n\t
  • Ingebouwde 6-axis IMU: MPU6886
  • \r\n\t
  • Ingebouwde rode LED
  • \r\n\t
  • Ingebouwde RTC: BM8563
  • \r\n\t
  • Ingebouwd power management IC: AXP192
  • \r\n\t
  • Operationele temperatuur: 0\u00b0C tot 40\u00b0C
  • \r\n\t
  • Afmeting: 48.2 x 25.5 x 13.7 mm
  • \r\n\t
  • Behuizing: Oranje plastic
  • \r\n

\r\n\r\n

*Let op: De batterij kan volledig leeg zijn bij levering, voordat het board werkt moet deze wellicht eerst een deel worden opgeladen.

\r\n\r\n

Gebruik aan/uit knop (Knop aan linkerzijde van module):

\r\n\r\n

    \r\n\t
  • Stroom aan: Druk de aan/uit knop voor 2 seconde in
  • \r\n\t
  • Stroom uit: Druk de aan/uit knop voor 6 seconde in
  • \r\n

\r\n\r\n

Inhoud verpakking:

\r\n\r\n

    \r\n\t
  • 1x M5StickC Plus
  • \r\n

\r\n\r\n

Zie de afbeeldingenen de pagina hieronder voor de pin layout.

\r\n\r\n

Voor meer informatie en om met het board te beginnen zie:M5StickC Plus.
